Analog standard size MG servo 15KG

Code VRSKM5515MA
Gear Full metal
Spline 25T
Motor DC motor
Bearing 2BB
Dead band 4μs default
Waterproof No
Operating Voltage DC4.8~6.0V
Working frequence      1520μs/50hz

FEATURE:
-- High performance analog standard servo

-- High-precision Taiwan-made metal gears( copper+ titamium)

--Middle CNC aluminium case

-- High quality brushed motor

-- Dual ball bearings

SPECIFICATIONS:
Operating Speed (4.8V): 0.18 sec/60 degrees
Operating Speed (6V): 0.16 sec/60 degrees
Stall Torque (4.8V): 14.25 kg.cm (197.93 oz/in)
Stall Torque (6V):  15.32 kgcm (212.79 oz/in)
Dimensions: 40.5X20.2X40.5mm /1.59 X0.80X1.58in
Weight:  60g (2.12oz)
Connector Wire Length: JR  265 mm (10.43in)

(600001367)

SKU 600001367
